AF自动对焦无畸变IMX258 1100万 4KP HDR带麦克风摄像头模组 免驱
立即咨询
全国咨询热线: 1
详情介绍
产品型号:QQSJ-8920
图像传感器/Image Sensor :1/2.8inch _4K Sensor
最大分辨率/ Maximum Resolution :3840H×2880V
像素大小/ Pixel Size :1.12um*1.12um
曝光系统/ Exposure System :自动曝光/Auto Exposure
电子快门/ Electronic Shutter :滚动快门/ Rolling Shutter
帧率/Frame:
MJPG:
320*240/30FPS;640*480/30FPS;800*600/30FPS;1280*720/30FPS;1024*768/30FPS;1280*960/30FPS;1600*1200/20FPS;1920*1080/30FPS;2048*1536/30FPS;2592*1944/20FPS;3264*2448/20FPS;3840*2160/30FPS;3840*2880/15FPS;
YUY2:
320*240/30FPS;640*480/30FPS;800*600/15FPS;1280*720/5FPS;1024*768/10FPS;1280*960/5FPS;1600*1200/5FPS;1920*1080/3FPS ;2048*1536/3FPS;2592*1944/1FPS;3264*2448/1FPS;3840*2160/1FPS;;3840*2880/1FPS;
接口速度/Transfer rates :480MB/S(USB2.0)
工作稳像温度/ Working Temp: 0℃ ~55℃
储存环境温度/ Storage Temp: 0℃ ~60℃
连接接口/Digital interface: 5-PIN_1.0MM_USB2.0
图像显示方向/ Direction :图像正立
产品尺寸/ Dimension :38MM(W)×38MM(L)× 7.3MM(H)
功耗/Power consumption :5.07V*0.22A,4K/30FPS(MJPG)
